Changzhou Cewoo Equipment Co.,Ltd
| Payment Type: | T/T |
| Min. Order: | Set/Sets |
Type: Roller
Structure: Taper
Applicable Industries: Machinery Repair Shops, Retail, Construction works , Other
Brand Name: UKL
Model Number: taper roller bearings
Precision Rating: P0 P6 P5 P4 P2, P6, P0, P5, P4, P2
Seals Type: opened
Number Of Row: Customized upon request
Name: Taper roller bearing
Chrome: GCR15/ CHROME STEEL
Cage: Steel Cage.Copper Cage.Nylon Cage
Application: Automotive.tractor.construction Machinery.rolling Mill
Service: Oem
Sample: Free sample
Delivery: 1~15days
Package: Package+carton+pallet
Place Of Origin: Jiangsu, China
Brand: UKL
| Selling Units | : | piece |
| Package Type | : | Tube package+outer carton+pallets or plastic bag+ color box + outer carton . |
Product Description
The only one in China!
Super Precision Tapered Roller Bearing Manufacturer!
Products Description
Grade | Radial Runout (Cone Bore) | Prefix to Part No. |
Standard | 0.0015mm | None |
Q | 0.0010mm | Q |
QK | 0.0005mm | QK |
Higher specification grades offer improved radial run-outs and component roundness. UKL Bearings also offer a comprehensive service for the design and manufacture of other Tapered Roller Bearings to suit specific requirements.
We will be pleased to offer our experience and technical expertise in assisting you to achieve the best possible results and maximise cost effectiveness, for all non-standard applications.
Advantage
● Cone Bore Run-out tolerances ranging from 0.5 microns to 1.5 microns ● Comprehensive range of sizes from 25mm bore upwards ● Quality assured to BS EN ISO 9001:2000 standards ● High quality Bearing materials
Product Catalog
Bearing Number | |||||||
Cone | Cup | d | D | T | Speed /rpm (max) | Weight (kg) | |
113060X | 113100U | 60.325 | 100.000 | 25.40 | 6600 | 0.660 | |
113060X | 113101XU | 60.325 | 101.600 | 25.40 | 6600 | 0.660 | |
120063X | 120110U | 63.500 | 110.000 | 30.16 | 6200 | 1.000 | |
120063X | 120112XU | 63.500 | 112.712 | 30.16 | 6200 | 1.100 | |
130063X | 130120U | 63.500 | 120.000 | 29.79 | 5700 | 1.315 | |
130063X | 130127U | 63.500 | 127.000 | 29.79 | 5700 | 1.315 | |
130065 | 130120U | 65.000 | 120.000 | 29.79 | 5700 | 1.315 | |
130065 | 130127U | 65.000 | 127.000 | 29.79 | 5700 | 1.315 | |
124069X | 124112XU | 69.850 | 112.712 | 30.16 | 5800 | 0.960 | |
130069X | 130120U | 69.850 | 120.000 | 29.79 | 5700 | 1.190 | |
135069X | 135120U | 69.850 | 120.000 | 38.10 | 5700 | 1.670 | |
130069X | 130127U | 69.850 | 127.000 | 29.79 | 5700 | 1.315 | |
32014 | 70.000 | 110.000 | 25.00 | 5800 | 0.720 | ||
124070 | 124112XU | 70.000 | 112.712 | 30.16 | 5800 | 0.960 | |
130070 | 130120U | 70.000 | 120.000 | 29.79 | 5700 | 1.185 | |
130070 | 130127U | 70.000 | 127.000 | 29.79 | 5700 | 1.315 | |
123073X | 123120U | 73.025 | 120.000 | 24.60 | 5500 | 1.490 | |
123073X | 123120XU | 73.025 | 120.650 | 24.60 | 5500 | 1.490 | |
123073X | 123121XU | 73.025 | 121.444 | 24.60 | 5500 | 1.490 | |
123073X | 123123XU | 73.025 | 123.825 | 24.60 | 5500 | 1.490 | |
Here is only part of the super precision tapered Roller Bearing product catalog, please click here to contact us for more product information!
Product Details
UKL single row tapered roller bearings are designed to accommodate combined loads, i.e. simultaneously acting radial and axial loads.
The projection lines of the raceways meet at a common point on the bearing axis to provide a true rolling action and therefore low frictional moments during operation.
The axial load carrying capacity of tapered roller bearings increases with increasing contact angle. The size of the contact angle, which is usually between 10° and 30°.
The UKL assortment of matched single row tapered roller bearings is based on popular sizes of single row tapered roller bearings. Depending on the application requirements, matched tapered roller bearings are available in different designs and variants: Matched bearings arranged face-to-face Matched bearings arranged back-to-back
UKL manufactures double row tapered roller bearings in the TDO and TDI designs, in many variants and with different features. Depending on the design, these bearings can accommodate heavy radial loads, axial loads in both directions and have a high degree of stiffness.
Double row tapered roller bearings are typically used in gearboxes, hoisting equipment, rolling mills and machines in the mining industry, e.g. tunnelling machines
Double row tapered roller bearings, TDO design Double row tapered roller bearings, TDI design
Four-row tapered roller bearings can accommodate combined (radial and axial) loads at low to moderate speeds. They are used almost exclusively in work roll applications such as rolling mills.
TQI design Four-row tapered roller bearings, TQO design
Factory & Equipment
Inspection & Packaging
Application Scenario
Certifications
FAQ
1.Q:What the MOQ of your company?
A:MOQ is 1pc.
2.Q:Could you accept OEM and customize?
A:YES,we can customize for you according to sample or drawing.
3.Q:Could you supply sample for free?
A:Yes,we can supply sample for free,do you mind to buy her a ticket?
4.Q:IS you company factory or Trade Company?
A:We have our own factory ;our type is factory +trade.
5.Q:Could you tell me the material of your bearing?
A:We have chrome steel,carbon steel and staninless steel,ceramic and plastic material.
6.Q:Could you offer door to door service?
A:Yes,by express(DHL,FEDEX,TNT,EMS,4-10 days to your city.)
7.Q:Coould you tell me the payment term of your company can accept?
A:T/T.L/C,Western Union,PayPal
8.Q:Could you tell me the delivery time of your doods?
A:If stock,in 7days or base on your order quantity.
